HOME > I.T Solution / SMT > SMT Assembly Line

SMT Assembly Line

SMT LINE

SMD



Solder Printer (HP-680S)		Mounter (SM320)



Mounter (SM421)		Reflower (Heller 1910MKV)



전자현미경 검사기 (HDMag 100)		질소발생기

Equipment List

Equipment	Model	Q'ty	Maker	Spec
Loader	SLD-120	1	SJ INNO TECH
Screen Printer	HP-680S	1	SJ INNO TECH
Chip Mounter	SM-320	1	SAMSUNG TECHWIN	Chip 0603mm 가능
이형 Mounter	SM-421	1	SAMSUNG TECHWIN	Chip 0402mm 가능
Reflow	HELLER 1910MKV	1	HELLER KOREA	PCB 폭 max 570mm, 질소 10존
Work Table	SMT-900X	2	SJ INNO TECH
UN-Loader	UL-100	1	KI HEUNG TECH
Vision Inspecter	SV-500 TLC	1	NEXSCIEN
전자현미경 검사기	HDMag 100	1	DAEDUK IMAGE
질소 발생기	TRN15-R-99	1	KSM	Max 2,000ppm
Chamber	DP-1200	1	SMC (KOREA)	DRY PORT
교반기		1	DIRECT & DEAL TECHNOLOGY
